J/22
Built by J Boats Tillotson Pearson (USA)
• Designed by Johnstone
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
First Built:
1983
Dimensions
Length Overall (LOA):
6.86 m
Length Waterline (LWL):
5.79 m
Beam:
2.44 m
Draft (Max):
1.16 m
Weight & Ballast
Displacement:
812 kg
Ballast:
318 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
10.14 m²
Mainsail Area:
10.91 m²
Sail Area:
21.05 m²
Sail Area (reported):
20.72 m²
I (Fore Triangle Height):
7.56 m
J (Fore Triangle Base):
2.68 m
P (Mainsail Hoist):
7.96 m
E (Boom Length):
2.74 m
Est. Forestay Length:
8.02 m
Engine & Systems
Engine Type:
Outboard
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calc):
24.64
SA/Displacement (Reported):
24.26
Ballast/Disp Ratio:
39.11%
Displacement/Length:
116.50
Comfort Ratio:
8.64
Capsize Screening:
2.64
S-Number:
5.06
Immersion:
97 kg/cm
