J/109
Built by J Boats Tillotson Pearson (USA)
• Designed by Johnstone
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
First Built:
2004
Dimensions
Length Overall (LOA):
10.74 m
Length Waterline (LWL):
9.30 m
Beam:
3.51 m
Draft (Max):
2.13 m
Weight & Ballast
Displacement:
4,944 kg
Ballast:
1,769 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
28.73 m²
Mainsail Area:
31.14 m²
Sail Area:
59.87 m²
Sail Area (reported):
59.83 m²
I (Fore Triangle Height):
14.17 m
J (Fore Triangle Base):
4.05 m
P (Mainsail Hoist):
13.18 m
E (Boom Length):
4.72 m
ISP:
15.12 m
Est. Forestay Length:
14.74 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3GM30
Engine Power:
27 HP
Fuel Capacity:
68 L
Water Capacity:
79 L
Performance Ratios
Hull Speed:
7.40 knots
SA/Displacement (Calc):
21.05
SA/Displacement (Reported):
21.03
Ballast/Disp Ratio:
35.78%
Displacement/Length:
171.51
Comfort Ratio:
20.40
Capsize Screening:
2.08
S-Number:
3.57
Immersion:
224 kg/cm
Notes
Shoal draft version: 5.75'/1.75m.
