J/125
Built by J Boats Tillotson Pearson (USA)
• Designed by Johnstone
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
First Built:
1997
Last Built:
2003
Number Built:
16
Dimensions
Length Overall (LOA):
12.50 m
Length Waterline (LWL):
11.28 m
Beam:
3.23 m
Draft (Max):
2.41 m
Weight & Ballast
Displacement:
3,787 kg
Ballast:
2,107 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
33.69 m²
Mainsail Area:
38.04 m²
Sail Area:
71.73 m²
Sail Area (reported):
71.72 m²
I (Fore Triangle Height):
14.94 m
J (Fore Triangle Base):
4.51 m
P (Mainsail Hoist):
13.87 m
E (Boom Length):
5.49 m
Est. Forestay Length:
15.60 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3GM30C
Engine Power:
30 HP
Fuel Capacity:
76 L
Water Capacity:
83 L
Performance Ratios
Hull Speed:
8.15 knots
SA/Displacement (Calc):
30.11
SA/Displacement (Reported):
30.11
Ballast/Disp Ratio:
55.64%
Displacement/Length:
73.59
Comfort Ratio:
14.56
Capsize Screening:
2.09
S-Number:
6.96
Immersion:
250 kg/cm
Notes
Carbon spar,carbon rudder. Special light weight hull. epoxy w/ carbon reinforcement.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
