IW-40
Built by IW-Varvet (SWE)
• Designed by Sparkman & Stephens
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1975
Dimensions
Length Overall (LOA):
12.10 m
Length Waterline (LWL):
9.15 m
Beam:
3.50 m
Draft (Max):
2.10 m
Weight & Ballast
Displacement:
9,000 kg
Ballast:
4,050 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
40.27 m²
Mainsail Area:
26.13 m²
Sail Area:
66.40 m²
Sail Area (reported):
66.43 m²
I (Fore Triangle Height):
15.54 m
J (Fore Triangle Base):
5.18 m
P (Mainsail Hoist):
13.72 m
E (Boom Length):
3.81 m
Est. Forestay Length:
16.39 m
Engine & Systems
Performance Ratios
Hull Speed:
7.34 knots
SA/Displacement (Calc):
15.66
SA/Displacement (Reported):
15.67
Ballast/Disp Ratio:
45.00%
Displacement/Length:
327.40
Comfort Ratio:
36.09
Capsize Screening:
1.70
S-Number:
1.46
Immersion:
220 kg/cm
Notes
S&S design #2186.
