ISLANDER 40 MS
Built by Islander (USA)
• Designed by Charles Davies
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Long Keel
Rigging Type:
Masthead Ketch
First Built:
1970
Dimensions
Length Overall (LOA):
13.41 m
Length Waterline (LWL):
9.91 m
Beam:
4.01 m
Draft (Max):
1.45 m
Weight & Ballast
Displacement:
12,701 kg
Ballast:
2,722 kg
Sail Plan
Foresail Area:
36.16 m²
Mainsail Area:
26.27 m²
Sail Area:
62.43 m²
Sail Area (reported):
66.89 m²
I (Fore Triangle Height):
13.72 m
J (Fore Triangle Base):
5.27 m
P (Mainsail Hoist):
11.89 m
E (Boom Length):
4.42 m
Est. Forestay Length:
14.69 m
Engine & Systems
Performance Ratios
Hull Speed:
7.64 knots
SA/Displacement (Calc):
11.71
SA/Displacement (Reported):
12.54
Ballast/Disp Ratio:
21.43%
Displacement/Length:
364.13
Comfort Ratio:
38.86
Capsize Screening:
1.74
S-Number:
0.97
Immersion:
273 kg/cm
Notes
Re-introduced as FREEPORT 41. (1972?)
