ISLANDER 36
Built by Islander Yachts (USA)
• Designed by Alan P. Gurney
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1971
Last Built:
1986
Number Built:
770
Dimensions
Length Overall (LOA):
11.00 m
Length Waterline (LWL):
8.61 m
Beam:
3.40 m
Draft (Max):
1.83 m
Max Height:
14.94 m
Weight & Ballast
Displacement:
6,101 kg
Ballast:
2,472 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
30.27 m²
Mainsail Area:
23.25 m²
Sail Area:
53.51 m²
Sail Area (reported):
53.51 m²
I (Fore Triangle Height):
13.72 m
J (Fore Triangle Base):
4.41 m
P (Mainsail Hoist):
11.96 m
E (Boom Length):
3.89 m
SPL/TPS:
4.57 m
Est. Forestay Length:
14.41 m
Engine & Systems
Engine Make:
Pathfinder
Engine Type:
Diesel
Engine Model:
50
Engine Power:
42 HP
Fuel Capacity:
121 L
Water Capacity:
204 L
Performance Ratios
Hull Speed:
7.12 knots
SA/Displacement (Calc):
16.35
SA/Displacement (Reported):
16.35
Ballast/Disp Ratio:
40.52%
Displacement/Length:
266.33
Comfort Ratio:
27.30
Capsize Screening:
1.88
S-Number:
1.97
Immersion:
201 kg/cm
Notes
With nearly 800 boats built this was one of the most successful models from Islander Yachts.
