HURLEY 30/90
Built by Hurley Marine
• Designed by Ian Anderson
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1972
Number Built:
30
Dimensions
Length Overall (LOA):
9.14 m
Length Waterline (LWL):
7.92 m
Beam:
2.90 m
Draft (Max):
1.37 m
Weight & Ballast
Displacement:
4,536 kg
Ballast:
1,542 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
21.66 m²
Mainsail Area:
12.85 m²
Sail Area:
34.51 m²
Sail Area (reported):
34.47 m²
I (Fore Triangle Height):
11.37 m
J (Fore Triangle Base):
3.81 m
P (Mainsail Hoist):
9.69 m
E (Boom Length):
2.65 m
Est. Forestay Length:
11.99 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
12 HP
Fuel Capacity:
45 L
Water Capacity:
121 L
Performance Ratios
Hull Speed:
6.83 knots
SA/Displacement (Calc):
12.85
SA/Displacement (Reported):
12.83
Ballast/Disp Ratio:
34.00%
Displacement/Length:
254.00
Comfort Ratio:
28.32
Capsize Screening:
1.77
S-Number:
1.71
Immersion:
158 kg/cm
Notes
Thanks to Nick Vass and the Hurley Owner Assoc. (site listed above) for images and information about all Hurley models.
