HURLEY 18
Built by Hurley Marine Ltd (UK)
• Designed by Ian L. Anderson
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
First Built:
1963
Last Built:
1972
Number Built:
377
Dimensions
Length Overall (LOA):
5.64 m
Length Waterline (LWL):
4.42 m
Beam:
2.03 m
Draft (Max):
0.99 m
Weight & Ballast
Displacement:
1,066 kg
Ballast:
454 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
3.18 m²
Mainsail Area:
3.87 m²
Sail Area:
7.06 m²
Sail Area (reported):
16.72 m²
I (Fore Triangle Height):
4.74 m
J (Fore Triangle Base):
1.34 m
P (Mainsail Hoist):
4.43 m
E (Boom Length):
1.75 m
Est. Forestay Length:
4.92 m
Engine & Systems
Performance Ratios
Hull Speed:
5.10 knots
SA/Displacement (Calc):
6.89
SA/Displacement (Reported):
16.33
Ballast/Disp Ratio:
42.55%
Displacement/Length:
344.12
Comfort Ratio:
18.46
Capsize Screening:
2.01
Immersion:
62 kg/cm
Notes
Before Hurley Marine went out of business the moulds were sold to Russell Curnow of Penzance, Cornwall who continued to build them up until about 1979. The moulds were then bought by Varne Yachts of Nottingham who were later taken over by Weston Boats who then went out of business in 1986. Over 900 H18s were built altogether.
