HANSE 510
Built by Hanse Yachts (GER)
• Designed by Berret Racoupeau Yacht Design
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
First Built:
2023
Dimensions
Length Overall (LOA):
15.97 m
Length on Deck (LOD):
15.25 m
Length Waterline (LWL):
14.40 m
Beam:
4.91 m
Draft (Max):
2.43 m
Max Height:
23.55 m
Weight & Ballast
Displacement:
16,540 kg
Ballast Type:
Cast iron
Sail Plan
Foresail Area:
59.32 m²
Mainsail Area:
57.94 m²
Sail Area:
117.26 m²
Sail Area (reported):
128.00 m²
I (Fore Triangle Height):
19.77 m
J (Fore Triangle Base):
6.00 m
P (Mainsail Hoist):
19.74 m
E (Boom Length):
5.87 m
Est. Forestay Length:
20.66 m
Engine & Systems
Engine Type:
Diesel, Saildrive
Engine Power:
80 HP
Fuel Capacity:
200 L
Water Capacity:
450 L
Performance Ratios
Hull Speed:
9.21 knots
SA/Displacement (Calc):
18.44
SA/Displacement (Reported):
20.13
Displacement/Length:
154.42
Comfort Ratio:
28.52
Capsize Screening:
1.95
S-Number:
3.51
Immersion:
486 kg/cm
Notes
Shallow keel draft: 1.98m / 6.5ft
