GRAVES 37
Built by Graves Yacht Yard (USA)
• Designed by J. Taylor
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
First Built:
1980
Dimensions
Length Overall (LOA):
11.33 m
Length Waterline (LWL):
9.35 m
Beam:
3.71 m
Draft (Max):
1.75 m
Max Height:
16.64 m
Weight & Ballast
Displacement:
7,357 kg
Ballast:
3,028 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
36.16 m²
Mainsail Area:
28.73 m²
Sail Area:
64.89 m²
Sail Area (reported):
64.85 m²
I (Fore Triangle Height):
15.21 m
J (Fore Triangle Base):
4.75 m
P (Mainsail Hoist):
13.56 m
E (Boom Length):
4.24 m
Est. Forestay Length:
15.93 m
Engine & Systems
Fuel Capacity:
189 L
Water Capacity:
379 L
Performance Ratios
Hull Speed:
7.42 knots
SA/Displacement (Calc):
17.51
SA/Displacement (Reported):
17.49
Ballast/Disp Ratio:
41.15%
Displacement/Length:
250.99
Comfort Ratio:
27.56
Capsize Screening:
1.93
S-Number:
2.21
Immersion:
238 kg/cm
Notes
The STARFLIGHT 38 was built to this same design by Starflight Yachts of Waterloo Ontario, CAN.
