GLADIATOR 24
Built by Continental Plastics Corp. (USA)
• Designed by William Lapworth
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin Keel
Rigging Type:
Fractional Sloop
First Built:
1958
Dimensions
Length Overall (LOA):
7.32 m
Length Waterline (LWL):
6.10 m
Beam:
2.29 m
Draft (Max):
1.22 m
Weight & Ballast
Displacement:
1,746 kg
Ballast:
930 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
11.18 m²
Mainsail Area:
14.52 m²
Sail Area:
25.71 m²
Sail Area (reported):
25.73 m²
I (Fore Triangle Height):
8.15 m
J (Fore Triangle Base):
2.74 m
P (Mainsail Hoist):
9.30 m
E (Boom Length):
3.12 m
Est. Forestay Length:
8.60 m
Engine & Systems
Performance Ratios
Hull Speed:
5.99 knots
SA/Displacement (Calc):
18.07
SA/Displacement (Reported):
18.09
Ballast/Disp Ratio:
53.25%
Displacement/Length:
214.84
Comfort Ratio:
19.16
Capsize Screening:
1.92
S-Number:
2.65
Immersion:
96 kg/cm
Notes
The GLADIATOR 24 is a raised deck version of the LAPWORTH 24, with a slightly shorter rig, and marginally lighter weight.
