EVOLUTION 22
Built by Evolution Yachts Ltd. (UK)
• Designed by Julian Everitt
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Lifting Keel
Rigging Type:
Masthead Sloop
First Built:
1978
Last Built:
1984
Number Built:
90
Dimensions
Length Overall (LOA):
6.63 m
Length Waterline (LWL):
5.21 m
Beam:
2.50 m
Draft (Max):
1.28 m
Draft (Min):
0.27 m
Weight & Ballast
Displacement:
1,479 kg
Ballast:
476 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
8.18 m²
Mainsail Area:
11.65 m²
Sail Area:
19.83 m²
Sail Area (reported):
19.79 m²
I (Fore Triangle Height):
7.25 m
J (Fore Triangle Base):
2.26 m
P (Mainsail Hoist):
8.20 m
E (Boom Length):
2.84 m
Est. Forestay Length:
7.60 m
Engine & Systems
Performance Ratios
Hull Speed:
5.54 knots
SA/Displacement (Calc):
15.57
SA/Displacement (Reported):
15.54
Ballast/Disp Ratio:
32.21%
Displacement/Length:
291.06
Comfort Ratio:
16.51
Capsize Screening:
2.21
S-Number:
1.70
Immersion:
89 kg/cm
Notes
Cruiser racer with fully retractable keel (locked down for sailing) allows the boat to float in only 10" of water and take the ground upright. Some have a masthead rig.
