ERICSON 35-2
Built by Ericson Yachts (USA)
• Designed by Bruce King
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
First Built:
1969
Last Built:
1981
Number Built:
500
Dimensions
Length Overall (LOA):
10.57 m
Length Waterline (LWL):
7.87 m
Beam:
3.05 m
Draft (Max):
1.50 m
Headroom:
1.88 m
Weight & Ballast
Displacement:
5,262 kg
Ballast:
2,268 kg
Sail Plan
Foresail Area:
27.96 m²
Mainsail Area:
21.54 m²
Sail Area:
49.50 m²
Sail Area (reported):
49.52 m²
I (Fore Triangle Height):
13.11 m
J (Fore Triangle Base):
4.27 m
P (Mainsail Hoist):
10.87 m
E (Boom Length):
3.96 m
Est. Forestay Length:
13.78 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Fuel Capacity:
85 L
Water Capacity:
95 L
Performance Ratios
Hull Speed:
6.81 knots
SA/Displacement (Calc):
16.70
SA/Displacement (Reported):
16.70
Ballast/Disp Ratio:
43.10%
Displacement/Length:
300.49
Comfort Ratio:
29.31
Capsize Screening:
1.77
S-Number:
1.72
Immersion:
165 kg/cm
Notes
Called the ERICSON 35-2 by convention as an earlier but relatively rare ERICSON 35 footer (1967?) exists which is an entirely different design, this later version is one of the most successful boats built by Ericson.
