ELAN E5
Built by Elan Yachts
• Designed by Humphreys Yacht Design
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Fin w/bulb & dual rudders
Rigging Type:
Fractional Sloop
First Built:
2014
Dimensions
Length Overall (LOA):
11.96 m
Length on Deck (LOD):
11.96 m
Length Waterline (LWL):
11.26 m
Beam:
3.87 m
Draft (Max):
2.40 m
Max Height:
19.75 m
Weight & Ballast
Displacement:
7,767 kg
Ballast:
2,700 kg
Sail Plan
Foresail Area:
35.81 m²
Mainsail Area:
43.47 m²
Sail Area:
79.28 m²
Sail Area (reported):
89.09 m²
I (Fore Triangle Height):
15.92 m
J (Fore Triangle Base):
4.50 m
P (Mainsail Hoist):
15.75 m
E (Boom Length):
5.52 m
Est. Forestay Length:
16.54 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Power:
38 HP
Fuel Capacity:
159 L
Water Capacity:
276 L
Performance Ratios
Hull Speed:
8.14 knots
SA/Displacement (Calc):
20.63
SA/Displacement (Reported):
23.18
Ballast/Disp Ratio:
34.77%
Displacement/Length:
151.65
Comfort Ratio:
23.83
Capsize Screening:
1.97
S-Number:
3.84
Immersion:
299 kg/cm
Notes
Formerly the Elan 400. Rebranded the E5 in 2014.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
