ELAN E1
Built by Elan Yachts
• Designed by Humphreys Yacht Design
Help improve this yacht's listing by uploading your own images.
General Information
Hull Type:
Lifting Keel
Rigging Type:
Fractional Sloop
First Built:
2017
Dimensions
Length Overall (LOA):
6.34 m
Length Waterline (LWL):
6.13 m
Beam:
2.50 m
Draft (Max):
1.55 m
Draft (Min):
0.50 m
Max Height:
10.60 m
Weight & Ballast
Displacement:
990 kg
Ballast:
360 kg
Sail Plan
Foresail Area:
10.98 m²
Mainsail Area:
13.07 m²
Sail Area:
24.05 m²
Sail Area (reported):
28.06 m²
I (Fore Triangle Height):
8.65 m
J (Fore Triangle Base):
2.54 m
P (Mainsail Hoist):
8.54 m
E (Boom Length):
3.06 m
Est. Forestay Length:
9.02 m
Engine & Systems
Water Capacity:
57 L
Performance Ratios
Hull Speed:
6.01 knots
SA/Displacement (Calc):
24.67
SA/Displacement (Reported):
28.78
Ballast/Disp Ratio:
36.37%
Displacement/Length:
119.83
Comfort Ratio:
10.07
Capsize Screening:
2.53
S-Number:
4.99
Immersion:
105 kg/cm
Notes
Optional 6 hp outboard engine and water capacity.
