ALBERG 22
Built by Nye Yachts (CAN)
• Designed by Carl Alberg
General Information
Hull Type:
Long Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1970
Number Built:
180
Dimensions
Length Overall (LOA):
6.71 m
Length Waterline (LWL):
4.88 m
Beam:
2.13 m
Draft (Max):
0.94 m
Weight & Ballast
Displacement:
1,451 kg
Ballast:
699 kg
Sail Plan
Foresail Area:
11.28 m²
Mainsail Area:
10.59 m²
Total Sail Area (calculated):
21.87 m²
Sail Area (reported):
21.93 m²
I (Fore Triangle Height):
8.46 m
J (Fore Triangle Base):
2.67 m
P (Mainsail Hoist):
7.32 m
E (Boom Length):
2.90 m
Engine & Systems
Performance Ratios
Hull Speed:
5.36 knots
SA/Displacement (Calculated):
17.06
SA/Displacement (Reported):
17.43
Ballast/Disp Ratio:
48.13%
Displacement/Length:
348.77
Comfort Ratio:
20.79
Capsize Screening:
1.90
S-Number:
1.43
Notes
An earlier version known as the DOUGLASS 22 was built by North American Fiberglass Mouldings.(CAN) Also known as the NORTH AMERICAN 22.
