BRISTOL 51.1
Built by Bristol Boat Company (USA)
• Designed by Dieter Empacher
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1987
Dimensions
Length Overall (LOA):
15.54 m
Length Waterline (LWL):
12.85 m
Beam:
4.62 m
Draft (Max):
3.20 m
Draft (Min):
1.62 m
Weight & Ballast
Displacement:
19,822 kg
Ballast:
8,845 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
63.92 m²
Mainsail Area:
49.42 m²
Total Sail Area (calculated):
113.34 m²
Sail Area (reported):
113.34 m²
I (Fore Triangle Height):
19.51 m
J (Fore Triangle Base):
6.55 m
P (Mainsail Hoist):
17.07 m
E (Boom Length):
5.79 m
Engine & Systems
Performance Ratios
Hull Speed:
8.70 knots
SA/Displacement (Calculated):
15.47
SA/Displacement (Reported):
15.80
Ballast/Disp Ratio:
44.62%
Displacement/Length:
260.15
Comfort Ratio:
40.31
Capsize Screening:
1.73
S-Number:
1.97
Notes
Bristol's of this size and vintage were built on a semi-custom basis so particulars vary.
