BRISTOL 33
Built by Bristol Yachts Inc. (USA)
• Designed by Halsey C. Herreshoff
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1968
Last Built:
1971
Dimensions
Length Overall (LOA):
10.24 m
Length Waterline (LWL):
7.95 m
Beam:
3.12 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
5,806 kg
Ballast:
2,313 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
23.23 m²
Mainsail Area:
20.33 m²
Total Sail Area (calculated):
43.56 m²
Sail Area (reported):
43.57 m²
I (Fore Triangle Height):
12.19 m
J (Fore Triangle Base):
3.81 m
P (Mainsail Hoist):
10.42 m
E (Boom Length):
3.90 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Fuel Capacity:
95 L
Water Capacity:
110 L
Performance Ratios
Hull Speed:
6.84 knots
SA/Displacement (Calculated):
13.48
SA/Displacement (Reported):
13.76
Ballast/Disp Ratio:
39.84%
Displacement/Length:
322.14
Comfort Ratio:
31.46
Capsize Screening:
1.76
S-Number:
1.35
Notes
Tall rig:
