YANKEE 30 MKI
Built by Yankee Yachts Inc. (USA)
• Designed by Sparkman & Stephens
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1970
Last Built:
1975
Number Built:
130
Dimensions
Length Overall (LOA):
9.16 m
Length Waterline (LWL):
7.01 m
Beam:
2.74 m
Draft (Max):
1.52 m
Weight & Ballast
Displacement:
3,946 kg
Ballast:
1,873 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
23.69 m²
Mainsail Area:
16.22 m²
Total Sail Area (calculated):
39.91 m²
Sail Area (reported):
39.95 m²
I (Fore Triangle Height):
12.19 m
J (Fore Triangle Base):
3.89 m
P (Mainsail Hoist):
10.64 m
E (Boom Length):
3.05 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Gas
Engine Model:
Atomic 4
Engine Power:
30 HP
Water Capacity:
83 L
Performance Ratios
Hull Speed:
6.43 knots
SA/Displacement (Calculated):
15.98
SA/Displacement (Reported):
16.32
Ballast/Disp Ratio:
47.47%
Displacement/Length:
319.22
Comfort Ratio:
28.68
Capsize Screening:
1.75
S-Number:
1.56
Notes
S&S design #1999.
