YAMAHA 36
Built by Yamaha
• Designed by Yamaha Design Team
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1979
Dimensions
Length Overall (LOA):
10.95 m
Length Waterline (LWL):
8.86 m
Beam:
3.61 m
Draft (Max):
2.01 m
Weight & Ballast
Displacement:
5,700 kg
Ballast:
2,549 kg
Sail Plan
Foresail Area:
35.00 m²
Mainsail Area:
24.73 m²
Total Sail Area (calculated):
59.73 m²
Sail Area (reported):
59.74 m²
I (Fore Triangle Height):
15.21 m
J (Fore Triangle Base):
4.60 m
P (Mainsail Hoist):
13.41 m
E (Boom Length):
3.69 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2QM20H
Engine Power:
20 HP
Fuel Capacity:
117 L
Water Capacity:
397 L
Performance Ratios
Hull Speed:
7.23 knots
SA/Displacement (Calculated):
18.72
SA/Displacement (Reported):
19.10
Ballast/Disp Ratio:
44.72%
Displacement/Length:
228.12
Comfort Ratio:
23.20
Capsize Screening:
2.04
S-Number:
2.60
