YAMAHA 33
Built by Yamaha
• Designed by Yamaha/Norlin
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1976
Dimensions
Length Overall (LOA):
10.17 m
Length Waterline (LWL):
8.20 m
Beam:
3.35 m
Draft (Max):
1.90 m
Headroom:
1.98 m
Weight & Ballast
Displacement:
4,400 kg
Ballast:
2,000 kg
Sail Plan
Foresail Area:
27.20 m²
Mainsail Area:
18.52 m²
Total Sail Area (calculated):
45.72 m²
Sail Area (reported):
45.71 m²
I (Fore Triangle Height):
12.95 m
J (Fore Triangle Base):
4.20 m
P (Mainsail Hoist):
11.40 m
E (Boom Length):
3.25 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
YSM-12
Engine Power:
12 HP
Fuel Capacity:
64 L
Water Capacity:
167 L
Performance Ratios
Hull Speed:
6.95 knots
SA/Displacement (Calculated):
17.03
SA/Displacement (Reported):
17.37
Ballast/Disp Ratio:
45.46%
Displacement/Length:
222.47
Comfort Ratio:
21.32
Capsize Screening:
2.07
S-Number:
2.49
