YAMAHA 26
Built by Yamaha Motor Co. Ltd. (JAP)
• Designed by Yamaha Design Team
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1979
Dimensions
Length Overall (LOA):
7.98 m
Length Waterline (LWL):
6.40 m
Beam:
2.80 m
Draft (Max):
1.55 m
Headroom:
1.55 m
Max Height:
11.29 m
Weight & Ballast
Displacement:
1,970 kg
Ballast:
650 kg
Sail Plan
Foresail Area:
11.52 m²
Mainsail Area:
15.47 m²
Total Sail Area (calculated):
26.99 m²
Sail Area (reported):
27.03 m²
I (Fore Triangle Height):
8.70 m
J (Fore Triangle Base):
2.65 m
P (Mainsail Hoist):
9.10 m
E (Boom Length):
3.40 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
1GM
Engine Power:
7.5 HP
Fuel Capacity:
25 L
Water Capacity:
70 L
Performance Ratios
Hull Speed:
6.14 knots
SA/Displacement (Calculated):
17.17
SA/Displacement (Reported):
17.54
Ballast/Disp Ratio:
33.00%
Displacement/Length:
209.36
Comfort Ratio:
15.50
Capsize Screening:
2.26
S-Number:
2.65
Notes
Based on 1/4 ton prototype, 'Magician IV', winner of Int. 1/4 ton cup in 1978.
