YAMAHA 24
Built by Yamaha (JAP)
• Designed by Yamaha Design Group
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1976
Dimensions
Length Overall (LOA):
7.42 m
Length Waterline (LWL):
6.50 m
Beam:
2.59 m
Draft (Max):
0.89 m
Weight & Ballast
Displacement:
1,650 kg
Ballast:
650 kg
Sail Plan
Foresail Area:
9.36 m²
Mainsail Area:
9.40 m²
Total Sail Area (calculated):
18.76 m²
Sail Area (reported):
18.67 m²
I (Fore Triangle Height):
7.77 m
J (Fore Triangle Base):
2.41 m
P (Mainsail Hoist):
6.49 m
E (Boom Length):
2.90 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
YSM8
Engine Power:
8 HP
Fuel Capacity:
25 L
Water Capacity:
36 L
Performance Ratios
Hull Speed:
6.19 knots
SA/Displacement (Calculated):
13.44
SA/Displacement (Reported):
13.63
Ballast/Disp Ratio:
39.39%
Displacement/Length:
167.36
Comfort Ratio:
14.62
Capsize Screening:
2.21
S-Number:
2.64
Notes
Motor Sailer.
