X-342
Built by X-Yachts (DEN)
• Designed by Niels Jeppesen
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1988
Last Built:
1994
Number Built:
105
Dimensions
Length Overall (LOA):
10.21 m
Length Waterline (LWL):
8.13 m
Beam:
3.28 m
Draft (Max):
1.86 m
Weight & Ballast
Displacement:
4,173 kg
Ballast:
1,950 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
21.54 m²
Mainsail Area:
30.83 m²
Total Sail Area (calculated):
52.37 m²
Sail Area (reported):
52.40 m²
I (Fore Triangle Height):
11.98 m
J (Fore Triangle Base):
3.60 m
P (Mainsail Hoist):
13.14 m
E (Boom Length):
4.69 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
2002
Engine Power:
18 HP
Performance Ratios
Hull Speed:
6.92 knots
SA/Displacement (Calculated):
20.20
SA/Displacement (Reported):
20.62
Ballast/Disp Ratio:
46.74%
Displacement/Length:
216.51
Comfort Ratio:
20.94
Capsize Screening:
2.06
S-Number:
2.89
Notes
Masthead Rig:
