WINNER 9.50
Built by Dick Rus Jachten B.V
• Designed by Cees van Tongeren
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1987
Dimensions
Length Overall (LOA):
9.50 m
Length Waterline (LWL):
7.60 m
Beam:
3.10 m
Draft (Max):
1.70 m
Max Height:
14.20 m
Weight & Ballast
Displacement:
3,500 kg
Ballast:
1,450 kg
Sail Plan
Foresail Area:
18.69 m²
Mainsail Area:
24.08 m²
Total Sail Area (calculated):
42.77 m²
Sail Area (reported):
42.74 m²
I (Fore Triangle Height):
11.00 m
J (Fore Triangle Base):
3.40 m
P (Mainsail Hoist):
11.20 m
E (Boom Length):
4.30 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
21 HP
Fuel Capacity:
53 L
Water Capacity:
151 L
Performance Ratios
Hull Speed:
6.69 knots
SA/Displacement (Calculated):
18.55
SA/Displacement (Reported):
18.91
Ballast/Disp Ratio:
41.43%
Displacement/Length:
222.32
Comfort Ratio:
20.26
Capsize Screening:
2.06
S-Number:
2.65
Notes
Shoal draft: 1.30m/4.27'.
