WINNER 11.20
Built by Winner Yachts
• Designed by Cees van Tongeren
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1992
Dimensions
Length Overall (LOA):
11.20 m
Length Waterline (LWL):
9.30 m
Beam:
3.60 m
Draft (Max):
1.95 m
Max Height:
17.10 m
Weight & Ballast
Displacement:
6,700 kg
Ballast:
2,900 kg
Sail Plan
Foresail Area:
27.67 m²
Mainsail Area:
35.69 m²
Total Sail Area (calculated):
63.36 m²
Sail Area (reported):
63.36 m²
I (Fore Triangle Height):
13.50 m
J (Fore Triangle Base):
4.10 m
P (Mainsail Hoist):
14.00 m
E (Boom Length):
5.10 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
29 HP
Performance Ratios
Hull Speed:
7.40 knots
SA/Displacement (Calculated):
17.83
SA/Displacement (Reported):
18.19
Ballast/Disp Ratio:
43.28%
Displacement/Length:
232.19
Comfort Ratio:
26.31
Capsize Screening:
1.93
S-Number:
2.47
Notes
Draft:(optional)
