WINDJAMMER 34
Built by Windjammer Yachts
General Information
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Cutter/Ketch
Construction:
FG
First Built:
1979
Number Built:
15
Dimensions
Length Overall (LOA):
10.42 m
Length Waterline (LWL):
8.74 m
Beam:
3.40 m
Draft (Max):
1.52 m
Headroom:
1.78 m
Weight & Ballast
Displacement:
9,163 kg
Ballast:
3,629 kg
Sail Plan
Foresail Area:
37.40 m²
Mainsail Area:
28.13 m²
Total Sail Area (calculated):
65.53 m²
Sail Area (reported):
65.03 m²
I (Fore Triangle Height):
13.41 m
J (Fore Triangle Base):
5.58 m
P (Mainsail Hoist):
11.66 m
E (Boom Length):
4.82 m
Engine & Systems
Performance Ratios
Hull Speed:
7.17 knots
SA/Displacement (Calculated):
14.97
SA/Displacement (Reported):
15.16
Ballast/Disp Ratio:
39.60%
Displacement/Length:
382.67
Comfort Ratio:
41.38
Capsize Screening:
1.64
S-Number:
1.12
Notes
Developed by Ron Vossler, based on the design of the Kendall 32 and Westsail 32.
