WESTERLY 22
Built by Westerly Marine Ltd. (UK)
• Designed by Denis Rayner
General Information
Hull Type:
Twin Keel
Rigging Type:
Gunter
Construction:
FG
First Built:
1963
Last Built:
1967
Number Built:
332
Dimensions
Length Overall (LOA):
6.78 m
Length Waterline (LWL):
5.59 m
Beam:
2.29 m
Draft (Max):
0.69 m
Weight & Ballast
Displacement:
1,429 kg
Ballast:
476 kg
Ballast Type:
Iron
Sail Plan
Sail Area (reported):
21.09 m²
Engine & Systems
Fuel Capacity:
83 L
Water Capacity:
83 L
Performance Ratios
Hull Speed:
5.74 knots
SA/Displacement (Reported):
16.95
Ballast/Disp Ratio:
33.33%
Displacement/Length:
228.34
Comfort Ratio:
17.04
Capsize Screening:
2.05
Notes
The first Westerly and derived from the earlier plywood WEST COASTER 20. Also available with a 'Bermudan' sloop rig as pictured here. A Volvo Penta M1 inboard was available as an option.
