WAVELENGTH 30
Built by W. D. Schock Corp.(USA)
• Designed by Paul Lindenberg
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1980
Last Built:
1981
Number Built:
10
Dimensions
Length Overall (LOA):
9.13 m
Length Waterline (LWL):
8.15 m
Beam:
3.05 m
Draft (Max):
1.60 m
Weight & Ballast
Displacement:
3,175 kg
Ballast:
1,406 kg
Sail Plan
Foresail Area:
22.85 m²
Mainsail Area:
18.39 m²
Total Sail Area (calculated):
41.24 m²
Sail Area (reported):
41.25 m²
I (Fore Triangle Height):
12.50 m
J (Fore Triangle Base):
3.66 m
P (Mainsail Hoist):
10.97 m
E (Boom Length):
3.35 m
Engine & Systems
Engine Make:
BMW
Engine Type:
Diesel
Performance Ratios
Hull Speed:
6.93 knots
SA/Displacement (Calculated):
19.10
SA/Displacement (Reported):
19.47
Ballast/Disp Ratio:
44.29%
Displacement/Length:
163.26
Comfort Ratio:
18.18
Capsize Screening:
2.09
S-Number:
3.51
Notes
Similar to the earlier LINDENBERG 30.
