WATERWITCH 30 MKI
Built by Various - mostly amateur built
• Designed by Maurice Griffiths
General Information
Hull Type:
Twin Keel
Rigging Type:
Masthead Ketch
Construction:
Wood/Steel
First Built:
1957
Dimensions
Length Overall (LOA):
9.14 m
Length Waterline (LWL):
7.92 m
Beam:
2.59 m
Draft (Max):
0.99 m
Weight & Ballast
Displacement:
4,309 kg
Ballast:
1,497 kg
Sail Plan
Sail Area (reported):
36.23 m²
Engine & Systems
Performance Ratios
Hull Speed:
6.83 knots
SA/Displacement (Reported):
13.96
Ballast/Disp Ratio:
34.74%
Displacement/Length:
241.30
Comfort Ratio:
31.20
Capsize Screening:
1.61
Notes
Among the most popular Griffiths designs that appeared in 'Yachting Monthly' Magazine during the late 1950's.
