WASA 270
Built by Wasa Yachts (SWE)
• Designed by Leif Ängermark
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1982
Dimensions
Length Overall (LOA):
8.29 m
Length Waterline (LWL):
7.20 m
Beam:
2.55 m
Draft (Max):
1.65 m
Weight & Ballast
Displacement:
2,100 kg
Ballast:
1,000 kg
Sail Plan
Foresail Area:
13.04 m²
Mainsail Area:
18.69 m²
Total Sail Area (calculated):
31.73 m²
Sail Area (reported):
31.77 m²
I (Fore Triangle Height):
8.69 m
J (Fore Triangle Base):
3.00 m
P (Mainsail Hoist):
9.85 m
E (Boom Length):
3.80 m
Engine & Systems
Performance Ratios
Hull Speed:
6.51 knots
SA/Displacement (Calculated):
19.35
SA/Displacement (Reported):
19.75
Ballast/Disp Ratio:
47.62%
Displacement/Length:
157.05
Comfort Ratio:
17.12
Capsize Screening:
2.01
S-Number:
3.64
