WARAN
Built by Werft (GER)
• Designed by J. Segger
General Information
Hull Type:
Fin w/rudder on partial skeg
Rigging Type:
Masthead Sloop
Construction:
FG
Dimensions
Length Overall (LOA):
8.60 m
Length Waterline (LWL):
7.43 m
Beam:
2.50 m
Draft (Max):
1.35 m
Weight & Ballast
Displacement:
2,350 kg
Ballast:
1,060 kg
Sail Plan
Foresail Area:
18.00 m²
Mainsail Area:
10.00 m²
Total Sail Area (calculated):
28.00 m²
Sail Area (reported):
28.80 m²
I (Fore Triangle Height):
9.00 m
J (Fore Triangle Base):
4.00 m
P (Mainsail Hoist):
8.00 m
E (Boom Length):
2.50 m
Engine & Systems
Water Capacity:
50 L
Performance Ratios
Hull Speed:
6.62 knots
SA/Displacement (Calculated):
15.84
SA/Displacement (Reported):
16.61
Ballast/Disp Ratio:
45.11%
Displacement/Length:
159.61
Comfort Ratio:
19.01
Capsize Screening:
1.90
S-Number:
3.11
Notes
Available with swing keel. Draft: .75m - 1.35m / 2.46' - 4.43'
