WAARSCHIP 700 LD
Built by Waarschuw (NL)
• Designed by Arthur Pelzer
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional (7/8) Sloop
Construction:
wood / epoxy
First Built:
2011
Dimensions
Length Overall (LOA):
7.00 m
Length Waterline (LWL):
6.90 m
Beam:
2.50 m
Draft (Max):
1.55 m
Weight & Ballast
Displacement:
1,150 kg
Ballast:
650 kg
Sail Plan
Foresail Area:
11.05 m²
Mainsail Area:
13.63 m²
Total Sail Area (calculated):
24.68 m²
Sail Area (reported):
32.40 m²
I (Fore Triangle Height):
8.18 m
J (Fore Triangle Base):
2.70 m
P (Mainsail Hoist):
8.26 m
E (Boom Length):
3.30 m
Engine & Systems
Performance Ratios
Hull Speed:
6.38 knots
SA/Displacement (Calculated):
22.48
SA/Displacement (Reported):
30.09
Ballast/Disp Ratio:
56.53%
Displacement/Length:
97.52
Comfort Ratio:
10.45
Capsize Screening:
2.41
S-Number:
5.23
