WAARSCHIP 28 LD
Built by Waarschuw (NL)
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
Plywood
First Built:
1994
Dimensions
Length Overall (LOA):
8.90 m
Length Waterline (LWL):
7.35 m
Beam:
3.07 m
Draft (Max):
1.80 m
Max Height:
13.30 m
Weight & Ballast
Displacement:
2,500 kg
Ballast:
1,050 kg
Sail Plan
Mainsail Area:
19.46 m²
Total Sail Area (calculated):
19.46 m²
Sail Area (reported):
48.60 m²
P (Mainsail Hoist):
10.52 m
E (Boom Length):
3.70 m
Engine & Systems
Performance Ratios
Hull Speed:
6.58 knots
SA/Displacement (Calculated):
10.56
SA/Displacement (Reported):
26.90
Ballast/Disp Ratio:
42.00%
Displacement/Length:
175.58
Comfort Ratio:
15.33
Capsize Screening:
2.28
S-Number:
2.04
Notes
Shallow draft keel: 1.2m / 3.92ft
