VISTA 585 TC (PASSPORT)
Built by Passport Yachts Inc. (TAIWAN)
• Designed by Bill Dixon
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Solent
Construction:
FG
First Built:
2010
Dimensions
Length Overall (LOA):
17.81 m
Length Waterline (LWL):
16.15 m
Beam:
5.33 m
Draft (Max):
2.41 m
Weight & Ballast
Displacement:
30,743 kg
Ballast:
9,979 kg
Ballast Type:
Lead
Sail Plan
Sail Area (reported):
151.52 m²
Engine & Systems
Engine Type:
Diesel
Engine Power:
180 HP
Fuel Capacity:
1,931 L
Water Capacity:
1,609 L
Performance Ratios
Hull Speed:
9.76 knots
SA/Displacement (Reported):
15.77
Ballast/Disp Ratio:
32.46%
Displacement/Length:
203.24
Comfort Ratio:
42.42
Capsize Screening:
1.72
Notes
TC = Twin cockpit
