VIKING (AAS)
Built by Bjarne Aas (NOR)
• Designed by Bjarne Aas
General Information
Hull Type:
Fin Keel
Rigging Type:
Fractional Sloop
Construction:
Wood
First Built:
1947
Dimensions
Length Overall (LOA):
9.50 m
Length Waterline (LWL):
6.30 m
Beam:
2.01 m
Draft (Max):
1.45 m
Weight & Ballast
Displacement:
2,850 kg
Ballast:
1,700 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
8.09 m²
Mainsail Area:
20.25 m²
Total Sail Area (calculated):
28.34 m²
Sail Area (reported):
30.01 m²
I (Fore Triangle Height):
7.35 m
J (Fore Triangle Base):
2.20 m
P (Mainsail Hoist):
10.00 m
E (Boom Length):
4.05 m
Engine & Systems
Performance Ratios
Hull Speed:
6.09 knots
SA/Displacement (Calculated):
14.10
SA/Displacement (Reported):
15.22
Ballast/Disp Ratio:
59.65%
Displacement/Length:
317.61
Comfort Ratio:
33.05
Capsize Screening:
1.43
S-Number:
1.42
