VIGGEN 23 (ALBIN)
Built by Karlskrona / Albin Marine
• Designed by Per Brohäll
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1966
Last Built:
1977
Number Built:
1430
Dimensions
Length Overall (LOA):
7.10 m
Length Waterline (LWL):
6.00 m
Beam:
2.24 m
Draft (Max):
1.11 m
Weight & Ballast
Displacement:
1,400 kg
Ballast:
600 kg
Sail Plan
Foresail Area:
8.33 m²
Mainsail Area:
9.26 m²
Total Sail Area (calculated):
17.59 m²
Sail Area (reported):
17.56 m²
I (Fore Triangle Height):
8.33 m
J (Fore Triangle Base):
2.00 m
P (Mainsail Hoist):
6.86 m
E (Boom Length):
2.70 m
Engine & Systems
Performance Ratios
Hull Speed:
5.94 knots
SA/Displacement (Calculated):
14.06
SA/Displacement (Reported):
14.30
Ballast/Disp Ratio:
42.87%
Displacement/Length:
180.75
Comfort Ratio:
16.11
Capsize Screening:
2.02
S-Number:
2.58
Notes
The VIGGEN was built by Karlskrona until 1971 (aprox.300 boats), after which they were built by Albin.(with modified keel and rudder.)
