VENTURE 21
Built by MacGregor Yachts Corp.(USA)
• Designed by Roger MacGregor
General Information
Hull Type:
Swing Keel
Rigging Type:
Cutter
Construction:
FG
First Built:
1966
Last Built:
1979
Dimensions
Length Overall (LOA):
6.40 m
Length Waterline (LWL):
5.64 m
Beam:
2.08 m
Draft (Max):
1.68 m
Draft (Min):
0.46 m
Headroom:
1.22 m
Weight & Ballast
Displacement:
680 kg
Ballast:
181 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
8.58 m²
Mainsail Area:
9.89 m²
Total Sail Area (calculated):
18.47 m²
Sail Area (reported):
16.26 m²
I (Fore Triangle Height):
7.34 m
J (Fore Triangle Base):
2.34 m
P (Mainsail Hoist):
6.65 m
E (Boom Length):
2.97 m
Engine & Systems
Engine Type:
Outboard
Engine Power:
10 HP
Water Capacity:
9 L
Performance Ratios
Hull Speed:
5.76 knots
SA/Displacement (Calculated):
23.89
SA/Displacement (Reported):
21.41
Ballast/Disp Ratio:
26.67%
Displacement/Length:
105.76
Comfort Ratio:
9.31
Capsize Screening:
2.39
S-Number:
5.26
Notes
The VENTURE 21 was the first (mono-hull) yacht built by MacGregor Yachts. It was updated and renamed MACGREGOR 21 in 1980.
