VENTURE 17
Built by MacGregor Yachts Corp. (USA)
• Designed by Roger Macgregor
General Information
Hull Type:
Swing Keel
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1968
Last Built:
1974
Dimensions
Length Overall (LOA):
5.28 m
Length Waterline (LWL):
4.57 m
Beam:
1.93 m
Draft (Max):
1.37 m
Draft (Min):
0.43 m
Weight & Ballast
Displacement:
408 kg
Ballast:
122 kg
Sail Plan
Foresail Area:
4.97 m²
Mainsail Area:
7.52 m²
Total Sail Area (calculated):
12.49 m²
Sail Area (reported):
14.03 m²
I (Fore Triangle Height):
4.66 m
J (Fore Triangle Base):
2.13 m
P (Mainsail Hoist):
5.64 m
E (Boom Length):
2.67 m
Engine & Systems
Performance Ratios
Hull Speed:
5.19 knots
SA/Displacement (Calculated):
22.71
SA/Displacement (Reported):
25.96
Ballast/Disp Ratio:
30.00%
Displacement/Length:
119.05
Comfort Ratio:
7.58
Capsize Screening:
2.62
S-Number:
4.79
Notes
Thanks to 'sea_scooter' for providing updated information.
