VANGUARD 15
Built by Team Vanguard (USA)
• Designed by Bob Ames
General Information
Hull Type:
Dbrd. Dinghy
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1992
Dimensions
Length Overall (LOA):
4.65 m
Length Waterline (LWL):
4.57 m
Beam:
1.68 m
Draft (Max):
1.04 m
Draft (Min):
0.15 m
Weight & Ballast
Displacement:
91 kg
Sail Plan
Sail Area (reported):
11.80 m²
Engine & Systems
Performance Ratios
Hull Speed:
5.19 knots
SA/Displacement (Reported):
59.46
Displacement/Length:
26.46
Comfort Ratio:
2.11
Capsize Screening:
3.76
