VANCOUVER 27
Built by Pheon Yachts Ltd. /Northshore Yachts Ltd.
• Designed by Robert B Harris
General Information
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Cutter
Construction:
GRP
First Built:
1973
Dimensions
Length Overall (LOA):
8.23 m
Length Waterline (LWL):
6.99 m
Beam:
2.64 m
Draft (Max):
1.37 m
Headroom:
1.88 m
Weight & Ballast
Displacement:
4,064 kg
Ballast:
1,572 kg
Ballast Type:
Cast iron
Sail Plan
Foresail Area:
21.74 m²
Mainsail Area:
13.66 m²
Total Sail Area (calculated):
35.40 m²
Sail Area (reported):
35.40 m²
I (Fore Triangle Height):
10.97 m
J (Fore Triangle Base):
3.96 m
P (Mainsail Hoist):
9.14 m
E (Boom Length):
2.99 m
Engine & Systems
Engine Make:
Bukh
Engine Type:
Diesel
Engine Power:
20 HP
Fuel Capacity:
106 L
Performance Ratios
Hull Speed:
6.42 knots
SA/Displacement (Calculated):
13.90
SA/Displacement (Reported):
14.18
Ballast/Disp Ratio:
38.67%
Displacement/Length:
332.21
Comfort Ratio:
32.29
Capsize Screening:
1.67
S-Number:
1.32
Notes
The Vancouver 27 was first built on a semi-production basis by Tradewind Boats in Port Coquitlam, British Columbia,CAN, followed by Philbrooks Shipyard and finally Seair Marine Ltd of British Columbia. In 1988, these molds were destroyed and construction of the boat ceased in North America.
