US 27
Built by US Yachts - Bayliner (USA)
• Designed by Doug Peterson (unauthorized)/Daryl Watson
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1983
Dimensions
Length Overall (LOA):
8.23 m
Length Waterline (LWL):
7.09 m
Beam:
2.90 m
Draft (Max):
1.58 m
Headroom:
1.83 m
Max Height:
11.84 m
Weight & Ballast
Displacement:
2,647 kg
Ballast:
918 kg
Sail Plan
Foresail Area:
16.35 m²
Mainsail Area:
12.68 m²
Total Sail Area (calculated):
29.03 m²
Sail Area (reported):
29.08 m²
I (Fore Triangle Height):
9.98 m
J (Fore Triangle Base):
3.28 m
P (Mainsail Hoist):
8.53 m
E (Boom Length):
2.97 m
Engine & Systems
Engine Make:
Volvo opt.
Engine Type:
Diesel
Fuel Capacity:
76 L
Water Capacity:
110 L
Performance Ratios
Hull Speed:
6.46 knots
SA/Displacement (Calculated):
15.17
SA/Displacement (Reported):
15.50
Ballast/Disp Ratio:
34.68%
Displacement/Length:
207.30
Comfort Ratio:
18.45
Capsize Screening:
2.11
S-Number:
2.44
Notes
Hull design began as the CHASER 29, a production IOR 1/2 racer designed by Doug Peterson and first built in 1975. Bayliner/US Yachts used a completely different deck and a number of other changes. Molds for this version were later sold to Pearson Yachts where, with still more alterations, it became the TRITON 27.
