US 22
Built by US Yachts - Bayliner (USA)
• Designed by Gary Mull
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1979
Dimensions
Length Overall (LOA):
6.71 m
Length Waterline (LWL):
6.07 m
Beam:
2.41 m
Draft (Max):
1.24 m
Headroom:
1.60 m
Max Height:
9.53 m
Weight & Ballast
Displacement:
1,111 kg
Ballast:
431 kg
Sail Plan
Foresail Area:
9.96 m²
Mainsail Area:
8.71 m²
Total Sail Area (calculated):
18.67 m²
Sail Area (reported):
18.77 m²
I (Fore Triangle Height):
7.54 m
J (Fore Triangle Base):
2.64 m
P (Mainsail Hoist):
7.62 m
E (Boom Length):
2.29 m
Engine & Systems
Performance Ratios
Hull Speed:
5.98 knots
SA/Displacement (Calculated):
17.40
SA/Displacement (Reported):
17.83
Ballast/Disp Ratio:
38.78%
Displacement/Length:
138.37
Comfort Ratio:
11.70
Capsize Screening:
2.35
S-Number:
3.66
Notes
Similar to the BUCCANEER 220. Derived from the RANGER 22. Later it became the TRITON 22 (built by Pearson Yachts). Available with a fixed keel, (deep and shoal), as well as a swing keel version.
