AJAX 28
Built by Ajax (CAN)
• Designed by C&C
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1978
Last Built:
1982
Number Built:
12
Dimensions
Length Overall (LOA):
8.52 m
Length Waterline (LWL):
7.06 m
Beam:
2.74 m
Draft (Max):
1.52 m
Headroom:
1.83 m
Weight & Ballast
Displacement:
2,812 kg
Ballast:
1,225 kg
Sail Plan
Foresail Area:
19.18 m²
Mainsail Area:
14.54 m²
Total Sail Area (calculated):
33.72 m²
Sail Area (reported):
33.82 m²
I (Fore Triangle Height):
11.23 m
J (Fore Triangle Base):
3.42 m
P (Mainsail Hoist):
9.54 m
E (Boom Length):
3.05 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
12 HP
Performance Ratios
Hull Speed:
6.45 knots
SA/Displacement (Calculated):
16.93
SA/Displacement (Reported):
17.31
Ballast/Disp Ratio:
43.55%
Displacement/Length:
222.52
Comfort Ratio:
20.86
Capsize Screening:
1.96
S-Number:
2.48
