TOP HAT 25
Built by Mouldcraft/G. Baker (AUSTRALIA)
• Designed by Illingworth & Primrose
General Information
Hull Type:
Fin Keel
Rigging Type:
Masthead Sloop
Construction:
Wood (cold molded)/FG
First Built:
1962
Last Built:
1990
Dimensions
Length Overall (LOA):
7.62 m
Length Waterline (LWL):
6.25 m
Beam:
2.44 m
Draft (Max):
1.30 m
Weight & Ballast
Displacement:
2,540 kg
Ballast:
1,134 kg
Ballast Type:
Lead
Sail Plan
Sail Area (reported):
26.57 m²
Engine & Systems
Performance Ratios
Hull Speed:
6.07 knots
SA/Displacement (Reported):
14.55
Ballast/Disp Ratio:
44.64%
Displacement/Length:
290.19
Comfort Ratio:
24.81
Capsize Screening:
1.80
Notes
Originally designed in the 1962 to the newly formed J.O.G. Four versions were produced. Mk 0 - Mk 3.
