TONIC 23 (JEANNEAU)
Built by Jeanneau (FRA)
• Designed by Philippe Harle
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1985
Last Built:
1989
Dimensions
Length Overall (LOA):
7.30 m
Length Waterline (LWL):
6.20 m
Beam:
2.50 m
Draft (Max):
0.70 m
Weight & Ballast
Displacement:
1,300 kg
Ballast:
449 kg
Sail Plan
Foresail Area:
9.48 m²
Mainsail Area:
13.59 m²
Total Sail Area (calculated):
23.07 m²
Sail Area (reported):
23.04 m²
I (Fore Triangle Height):
7.90 m
J (Fore Triangle Base):
2.40 m
P (Mainsail Hoist):
8.49 m
E (Boom Length):
3.20 m
Engine & Systems
Performance Ratios
Hull Speed:
6.04 knots
SA/Displacement (Calculated):
19.37
SA/Displacement (Reported):
19.72
Ballast/Disp Ratio:
34.54%
Displacement/Length:
152.27
Comfort Ratio:
12.54
Capsize Screening:
2.31
S-Number:
3.72
Notes
A keel/cb version was also available.
