TOMAHAWK 25
Built by Marine Construction (UK)
• Designed by Alan Hill
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1970
Number Built:
300
Dimensions
Length Overall (LOA):
7.72 m
Length Waterline (LWL):
6.10 m
Beam:
2.59 m
Draft (Max):
1.42 m
Weight & Ballast
Displacement:
2,298 kg
Ballast:
998 kg
Sail Plan
Foresail Area:
14.43 m²
Mainsail Area:
10.63 m²
Total Sail Area (calculated):
25.06 m²
Sail Area (reported):
26.66 m²
I (Fore Triangle Height):
9.26 m
J (Fore Triangle Base):
3.12 m
P (Mainsail Hoist):
7.77 m
E (Boom Length):
2.74 m
Engine & Systems
Water Capacity:
76 L
Performance Ratios
Hull Speed:
5.99 knots
SA/Displacement (Calculated):
14.39
SA/Displacement (Reported):
15.61
Ballast/Disp Ratio:
43.43%
Displacement/Length:
282.70
Comfort Ratio:
20.95
Capsize Screening:
1.98
S-Number:
1.68
Notes
Roughly half were delivered with bilge keels. (Draft 3.0').
