AJAX (LEE)
Built by Halmatic (UK)
• Designed by Oliver Lee
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1966
Last Built:
1968
Number Built:
55
Dimensions
Length Overall (LOA):
7.09 m
Length Waterline (LWL):
5.84 m
Beam:
1.96 m
Draft (Max):
1.12 m
Weight & Ballast
Displacement:
862 kg
Sail Plan
Foresail Area:
6.95 m²
Mainsail Area:
10.47 m²
Total Sail Area (calculated):
17.42 m²
Sail Area (reported):
17.47 m²
I (Fore Triangle Height):
5.94 m
J (Fore Triangle Base):
2.34 m
P (Mainsail Hoist):
6.71 m
E (Boom Length):
3.12 m
Engine & Systems
Performance Ratios
Hull Speed:
5.87 knots
SA/Displacement (Calculated):
19.23
SA/Displacement (Reported):
19.65
Displacement/Length:
120.59
Comfort Ratio:
12.09
Capsize Screening:
2.08
S-Number:
4.25
Notes
Spin. SA: 220 sq.ft./20.5 m2
