TM 42
Built by Tradition Marine
• Designed by Joubert-Nivelt
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
GRP
First Built:
2001
Last Built:
2013
Number Built:
5
Dimensions
Length Overall (LOA):
12.85 m
Length Waterline (LWL):
9.70 m
Beam:
3.80 m
Draft (Max):
1.85 m
Weight & Ballast
Displacement:
9,870 kg
Ballast:
3,160 kg
Sail Plan
Foresail Area:
34.14 m²
Mainsail Area:
35.10 m²
Total Sail Area (calculated):
69.24 m²
Sail Area (reported):
90.15 m²
I (Fore Triangle Height):
14.75 m
J (Fore Triangle Base):
4.63 m
P (Mainsail Hoist):
13.50 m
E (Boom Length):
5.20 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Power:
55 HP
Performance Ratios
Hull Speed:
7.56 knots
SA/Displacement (Calculated):
15.05
SA/Displacement (Reported):
20.00
Ballast/Disp Ratio:
32.02%
Displacement/Length:
301.52
Comfort Ratio:
33.43
Capsize Screening:
1.79
S-Number:
1.61
Notes
Thanks to TM 42 owner Pau Doménech for sending information and a photo.
