TIGER 25 (WESTERLY)
Built by Westerly Marine Ltd. (UK)
• Designed by John Butler
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1969
Last Built:
1976
Number Built:
284
Dimensions
Length Overall (LOA):
7.64 m
Length Waterline (LWL):
6.65 m
Beam:
2.67 m
Draft (Max):
1.30 m
Weight & Ballast
Displacement:
2,388 kg
Ballast:
1,016 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
15.25 m²
Mainsail Area:
14.31 m²
Total Sail Area (calculated):
29.56 m²
Sail Area (reported):
29.54 m²
I (Fore Triangle Height):
9.91 m
J (Fore Triangle Base):
3.08 m
P (Mainsail Hoist):
8.53 m
E (Boom Length):
3.35 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
MD1B
Engine Power:
10 HP
Performance Ratios
Hull Speed:
6.26 knots
SA/Displacement (Calculated):
16.55
SA/Displacement (Reported):
16.86
Ballast/Disp Ratio:
42.55%
Displacement/Length:
225.90
Comfort Ratio:
19.84
Capsize Screening:
2.01
S-Number:
2.40
